Product Features :

It has the function of storing process parameters and flexible program calling.

The traction station adopts servo control, and the auxiliary shaft of feeding and unwinding adopts torque motor control, with high synchronization precision and adjustable speed.

This equipment has intermittent feeding mode and continuous feeding mode, which can be switched flexibly according to different reading and writing methods; chip counting, meter counting alarm shutdown function, and can automatically control the device to stop according to the set quantity.

Each retracting and unwinding shaft is equipped with a one-button start/stop button, which is more convenient for the operator to change the material.

With safety protection function; it can automatically stop running when approaching the dangerous area of the equipment, and protect personal safety to the maximum extent (optional).

Automatic deviation correction device (to ensure the stability of the material and prevent abnormal stoppage of code reading and writing caused by material deviation during the detection process).

The equipment has the functions of code reading, writing, and code locking, and visual detection of one-dimensional and two-dimensional code characters can be read without additional equipment.

Defective product ribbon marking/defective product shaving platform, two processing methods, more humane and more efficient.

For special materials, the equipment is equipped with ultrasonic cutting function, which is more expandable and can meet customers’ subsequent product needs in an all-round way. The product can be collected automatically in sheets or in rolls.

Application:

Writing and testing of RFID tag procedures, involving various  Industries such as electronics, logistics, clothing, ETC,

Anti-counterfeiting, traceability and other industries.
